IRDB0014
Smart Door Bell
Customization: Available Night
Vision: With Night Vision
Type: Wired
Product Detail
| Model NO. | IRDB0014 | Color | Black |
| Voice Service | Without Voice Service | Certification | RoHS, CE |
| WiFi | 2.4GHz | Angle | 165 |
1080P TUYA WIFI DOORBELL WITH UNLOCK FUNCTION
| Model:IRDB0014 | ||
| SYSTEM | CPU | GK7202V300 |
| Nor Flash | 16MB | |
| SDRAM | 64MB DDR2 (Built-in CPU) | |
| Image Sensor | GC2053 | |
| SYSTEM | Liteos | |
| CAMERA CONFIG | Image Sensor Config. | 1/2.9" CMOS |
| Field of View (FOV) | 165° | |
| Lens Mount | M12 | |
| Day & Night | Automatic IR cut filter | |
| IMAGE | Resolution | 1920 × 1080 pixel |
| Frame | 20 FPS | |
| COMPRESSION | Video Compression | H.265 |
| H.265 Encoding | H.265 main profile@level5.1 Main Tier | |
| Video Compression Rate | FHD | |
| WiFi | WiFi Standards | IEEE802.11b, 802.11g, 802.11n Draft |
| Frequency Range | 2412MHz ~ 2472MHz | |
| Channel Bandwidth | Supports 20MHz,40MHz | |
| Safety | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK | |
| Speed | 11b: 11Mbps, 11g :54Mbps, 11n :150Mbps | |
| INTERFACES | TYPE-C USB | *1/ TYPE-c USB 5V 2A Power Supply |
| Battery Compartments | *1/ Lithium battery Power Supply (3000mAH) | |
| Power Switch | *1 | |
| Reset | *1 | |
| MIC | *1 | |
| Speaker | *1 | |
| TF Card Slot | *1 | |
| Indicator Light | *1/ White LED indicator light | |
| Photosensitive Diode | *1 | |
| PIR | *1 | |
| 2.4G Antenna | *1/ Built-in 2.4G Antenna | |
| FEATURES | Storage |
Support MicroSD /Max 64G Support Alarm Record |
| PIR Detection | Up to 1.5m in distance | |
| Human Figure Detection | Supported | |
| Night Vision | Up to 2.5m in distance | |
| Talkback | One-way audio/ Two-way audio | |
| OTA Upgrade | Supported | |
| Pairing | Scan QR code | |
| Mobile App for monitoring | Tuya APP for andorid & iOS | |
| OTHERS | Operating Condition |
Temperature: -10 °C to +50 °C Humidity:< 95% |
| Power Supply | TYPE-C USB 5V 2A / 5V 8W Solar panel / DC12-15V 1A adapter / 12-15V DIN adapter | |
| Power Consumption | ≤ 1W | |
| Size | 150*61*39mm | |
| Weight | 236g | |
